Machine Detail Image
Specification
| Item | Value |
| Model | ZS-CDD16 |
| Driving mode | automatic navigation, handheld driving |
| Navigation mode | Laser SLAM |
| Tray type | Chuanzi |
| Rated load capacity | 1600kg |
| Load center distance |
600mm
|
| Navigation position accuracy | ± 10mm |
|
Navigation angle accuracy
|
± 0.5 ° |
| Fork positioning accuracy | ± 10mm |
| Standard lifting height | 3000mm |
| Gate frame deployment height | 3500mm |
| Fork height above ground (when the fork is at its lowest position) | ≤ 90mm |
| Navigation laser scanning height | 2015 ± 10mm |
| Fork size | 1220mm * 185mm * 55mm |
| Fork outer width | 550/600/685mm |
| Right angle stacking channel width | 2230+200mm |
| Map area | ≤ 400000 meters ² |
| Minimum turning radius | 1340+200mm |
| Driving speed | 2 m/s |
| Lifting speed: full load/no load | 100/180 mm/s |
| Descent speed: full load/no load | 245/230 mm/s |
| Passing ability (slope/steps/gaps) | <5%/5mm/15mm |
| Tire size: Drive wheel | 248x75mm |
| Tire size: Load bearing wheel | 84x70mm |
| Battery specification | 24V/173Ah (lithium iron phosphate) |
| Tire size: Balance wheel | 115x55mm |
| Number of wheels | Drive wheel/Balance wheel/Load bearing wheel: 1/2/4 |
| Battery weight | 60kg |
| Comprehensive endurance | 8-10h |
| Charging parameters | 24V/100A |
| Charging time | 2 hours |
| Charging mode | automatic/manual |
| Battery cycle count | >2000 |
Features
ZS-CDD16 AGV is a high-precision and high-efficiency vehicle recognition device.
It can accurately identify forked goods and help improve handling efficiency. Not only does it support the identification of national, European, and non-standard pallets, but it also offers a wide range of optional services to meet the needs of different industries.
In terms of safety, the ZS-CDD16 AGV is equipped with a 360 ° obstacle avoidance laser scanning range and various sensor solutions, such as 3D cameras, safety contacts, distance sensors, etc., to ensure the safety of the AGV during transportation and provide safe escort, making transportation more reassuring.
In summary, ZS-CDD16 AGV is an efficient, safe, and multifunctional vehicle identification device suitable for different scenarios, providing convenient logistics services for various industries.
Shipping
Package:
1)Standard box package for light and small item;
2)Strong wood package for heavy and large equipment;
Delivery:
1.By air:sample and small package,worldwide expresses like DHL,UPS,FEDFX,EMS...
2.By sea:large package and quantity.
3.By car,by train or other ways acoording to customers' requirements.
4.The wooden box photo is below.
Contact me
FAQ
1.How to control this AGV ?
This ZS-CDD16 comes with a control button, which can be controlled through the controller or operated through the button
2. How can you get our help and after-sale service?
We have offices overseas in USA, Mexico, India, Thailand, Russia, etc. If you have technical problems,we can help.
3. what services can we provide?
1. Quickly respond to inquiries and resolve your questions as soon as possible
2. Careful and responsible after-sales service to solve all problems you encounter after receiving the machine
3. Technical service provision. Our company has technical offices in multiple countries and can provide you with machine technology services nearby
