GKG-K870 Full Automatic Solder Paste Printer for SMT PCBA assembly factory
Machine Detail Image
Specification
| Item | Value |
| Model |
ZS-400 |
|
Dimension |
1650×700×810mm |
|
Platform size |
300×500mm |
|
PCB size |
250×450mm |
|
Apply template dimension |
250×680mm |
|
Printing speed |
0-8000mm/min |
|
PCB thickness |
0-100mm |
|
PCB tuning range |
Front/side±10mm |
|
Supply voltage |
1PAC220V 50/60HZ |
|
Print Height |
850±20mm |
|
Repeat accuracy |
±0.01mm |
|
PCB positioning way |
Profile outside/Reterence benchmark hole |
|
Weight |
Approx.380Kg |
Features
1, a Taiwan high-speed precision wheel Guide and infinite frequency conversion timing motor-driven blade, ensure that the printing precision.
2, the blade can slide back and forth in order to choose the right printing locations.
3, printed blade can rotate 45 ° fixed, easy cleaning and replacement of the printing plate and blade.
4, the School Board uses steel NET mobile, x, y, correction and print platform fine-tuning handle, convenient and quick.
5, Using Mitsubishi PLC and man-machine interface touch screen, simple operation, convenient Man-machine dialogue.
6, the printing times can be set, also are free to select a variety of printing mode, parameter set is very convenient.
7 automatic count function to facilitate the production of statistics or quantitative production.
8, with automatic, semi-automatic and manual modes of operation: automatic (machine maintenance), semi-automatic (Typical), jog (debug).
9, table equipped with magnetic cellular platforms; single or double panel positioning flexibility is very high.
10, blade angle, pressure, stroke adjustable, Blade, rubber blade can be used.
11, clean steel alarm function, easy to clear scrub Board to ensure printing quality.
12, floating blade system enables more flexible printing, blade free and automatic adjustment with with steel mesh level fluctuations
Shipping
Package:
1.Inner packing :vacuum packing/plastic bag.
2.Standard carton packing/ESD packing
3.Customized packing.
Delivery:
1.By air:sample and small package,worldwide expresses like DHL,UPS,FEDFX,EMS...
2.By sea:large package and quantity.
3.By car,by train or other ways acoording to customers' requirements.
4.The wooden box photo is below.
Certifications
FAQ
1.what can you buy from us?
SMT whole production line,chip mounter,AOI inspection machine,pick and place machine,reflow oven and so on.
2. How can you get our help and after-sale service?
We have offices overseas in USA, Mexico, India, Thailand, Russia, etc. If you have technical problems,we can help.
3.What we can do?
1、PLC&PC research
2、Hardware development
3、Process&Quality Improvement
4、Customize for customer
5、On-site lean management
6、Market analysis&planning
